500 to 20000 Ltr SS Double Limpet Coil Jacketed Reactor

Get a Price/Quote

MOQ : 1 Piece

500 to 20000 Ltr SS Double Limpet Coil Jacketed Reactor Specification

Storage Material
Chemical, Pharmaceutical, Liquid, etc.

Body Material
Stainless Steel (SS)

Orientation
Vertical

Shape
Cylindrical

Storage Capacity
500 to 20000 Ltr

Usage
Industrial

Size
500 to 20000 Ltr

Product Type
Reactor

Coil Type
Double Limpet Coil

Agitator Type
Mounted/Customized (Motorized)

Jacket Material
Stainless Steel

Internal Finish
Mirror/Matte Polished

Vessel Thickness
8 mm to 25 mm (as per capacity and design)

Design Standard
ASME, DIN, IS Code (upon request)

Mounting
On legs/supports/skids

Reactor Type
Double Limpet Coil Jacketed

External Finish
Painted/SS Polished

Manhole Diameter
300 mm to 600 mm

Seal Type
Mechanical Seal/Gland Packing

Testing
Hydrostatic Pressure and Quality Testing

Nozzle/Port Configuration
Customized as per process requirement

Agitator Speed
Variable (up to 1440 RPM)

Applications
Chemical Reaction, Mixing, Blending, Pharmaceutical, Food Processing

Operating Pressure
Up to 10 Bar (customizable)

Accessories
Pressure Relief Valve, Temperature Gauge, Sampling Point, Sight Glass

Operating Temperature
-10°C to 250°C

500 to 20000 Ltr SS Double Limpet Coil Jacketed Reactor Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Day

Delivery Time
10 Days

About 500 to 20000 Ltr SS Double Limpet Coil Jacketed Reactor

A 500 to 20000 Ltr SS Double Limpet Coil Jacketed Reactor is a specialized vessel used in various industrial processes, particularly in chemical, pharmaceutical, and food processing applications. It is suitable for a wide range of production scales, from laboratory experiments to full-scale industrial processes. The double limpet coil design maximizes heat transfer efficiency, allowing for precise temperature control. This can be tailored to specific process requirements, including different heating/cooling media and control systems. 500 to 20000 Ltr SS Double Limpet Coil Jacketed Reactor is a versatile and efficient solution for various industrial processes, ensuring precise temperature control and high-quality production outcomes.
